Geneflex™ EPDM/PE Suction Hose

Enquire
Pipes

Description

Concreflex™ TPU hose is specifically designed for cement pouring, featuring exceptional flexibility and a lightweight construction. Its easy handling and portability make it perfect for efficient cement shimming on construction sites. The hose is highly durable, ensuring reliable performance in demanding environments, while its design allows for smooth and hassle-free operation during concrete pumping.

Basic information

• Size:
1"-6"
• Standard Color:
  (Other colours available)
• Length:
Up to 30m, customized lengths available
• Application:
• Vacuum Pumps Dewatering
• Frack Liquid Removal
• Marine Bilge Discharge
• Agriculture Liquid Fertilizers
• Liquid Manure Handling
• Irrigation

Structure

• High-grade Rubber Compounds
• Rigid Polyethylene Helix

Features

• Excellent Flexibility
• Cold-Resistance Raw Material

Data Sheet

Code ID OD Wall Thickness Weight Minimum Bend Radius Working pressure at 40℃ Vacuum rating at 40℃
Inch mm mm mm kg/m m MPa kPa
E/P02501
ID:
Inch: 1"
Mm: 25.4(+1.5, -0)
OD (mm): 36.5 (+1.5, -0)
Wall Thickness (mm): 5.5～6.5
Weight (kg/m): 0.46
Minimum bend radius (m): 0.060
Working pressure at 40℃ (MPa): 0.30
Vacuum rating at 40℃ (kPa): 94.81
1" 25.4(+1.5, -0) 36.5 (+1.5, -0) 5.5～6.5 0.46 0.060 0.30 94.81
E/P04001
ID:
Inch: 1-1/2
Mm: 38.1 (+1.5, -0)
OD (mm):50.5 (+1.5, -0)
Wall Thickness (mm): 5.5～6.5
Weight (kg/m): 0.62
Minimum bend radius (m): 0.080
Working pressure at 40℃ (MPa): 0.24
Vacuum rating at 40℃ (kPa): 94.81
1-1/2 38.1 (+1.5, -0) 50.5 (+1.5, -0) 5.5～6.5 0.62 0.080 0.24 94.81
E/P04001
ID:
Inch: 1-3/4
Mm: 44.5 (+1.5, -0)
OD (mm): 54.0 (+1.5, -0)
Wall Thickness (mm): 4.5～5.5
Weight (kg/m): 0.80
Minimum bend radius (m): 0.105
Working pressure at 40℃ (MPa): 0.24
Vacuum rating at 40℃ (kPa): 94.81
1-3/4 44.5 (+1.5, -0) 54.0 (+1.5, -0) 4.5～5.5 0.80 0.105 0.24 94.81
E/P05001
ID:
Inch: 2"
Mm: 50.8 (+1.5, -0)
OD (mm): 62.0 (+1.5, -0)
Wall Thickness (mm): 5.5～6.5
Weight (kg/m): 0.95
Minimum bend radius (m): 0.125
Working pressure at 40℃ (MPa): 0.24
Vacuum rating at 40℃ (kPa): 94.81
2" 50.8 (+1.5, -0) 62.0 (+1.5, -0) 5.5～6.5 0.95 0.125 0.24 94.81
E/P08001
ID:
Inch: 3"
Mm: 75.2 (+1.5, -0)
OD (mm): 86.5 (+1.5, -0)
Wall Thickness (mm): 6.5～7.5
Weight (kg/m): 1.5
Minimum bend radius (m): 0.180
Working pressure at 40℃ (MPa): 0.21
Vacuum rating at 40℃ (kPa): 88.04
3" 75.2 (+1.5, -0) 86.5 (+1.5, -0) 6.5～7.5 1.5 0.180 0.21 88.04
E/P10001
ID:
Inch: 4"
Mm: 100.8 (+1.5, -0)
OD (mm): 116.5 (+1.5, -0)
Wall Thickness (mm): 8.0～9.0
Weight (kg/m): 2.40
Minimum bend radius (m): 0.300
Working pressure at 40℃ (MPa): 0.17
Vacuum rating at 40℃ (kPa): 88.04
4" 100.8 (+1.5, -0) 116.5 (+1.5, -0) 8.0～9.0 2.40 0.300 0.17 88.04
E/P15001
ID:
Inch: 6"
Mm: 151.1 (+1.5, -0)
OD (mm): 168.0 (+1.5, -0)
Wall Thickness (mm): 8.5～9.5
Weight (kg/m): 4.00
Minimum bend radius (m): 0.510
Working pressure at 40℃ (MPa): 0.14
Vacuum rating at 40℃ (kPa): 81.26
6" 151.1 (+1.5, -0) 168.0 (+1.5, -0) 8.5～9.5 4.00 0.510 0.14 81.26
